Control Functions of Mechanism
44
Anti-tilting Lock Switch
1. When starting the Front Suspension Lock function, it
will trigger the Front Suspension Caliper and the Disk
to carry out the locking. Such function helps the rider
keep the motorcycle in the upright position when
stopping or parking the vehicle.
2. When pressing this switch, the motorcycle will be
maintained at the current vehicle angle.
Front wheel anti-tilting lock release / Front wheel
anti-tilting lock:
Match the buttons with the illustrated diagram shown.
1. Lock release 2. Anti-tilting lock 3. Anti-tilting lock indicator
1. When the main switch is turned on, if it is unlocked,
the indicator will flash; the indicator will stay lit when
locked.
2. When starting the vehicle, if the throttle opening is
greater than the unlocking threshold, it will
automatically unlock. The lock button will be inactive
while riding, and can only be manually locked when
the speed is lower than the locking threshold.
3. When pressing the Lock Switch, the Front
Suspension Lock warning screen will constantly light
up in white and the Buzzer will also sound once.
4. When pressing the Unlock Switch, the Front
Suspension Lock warning screen will flicker in white
and the Buzzer will also sound twice.
Locking condition when idling: engine speed < 2000
rpm and wheel speed < 13 km/h
Unlocking condition for anti-tilting: > 2200 rpm and
wheel speed >2km/h
If the engine is on, do not turn the throttle handle when
walking the vehicle manually. When the speed
reaches the unlocking threshold, after being unlocked,
the 2-wheel vehicle can easily become unstable and
To Next Page
