KYMCO CV3 Series User Manual

3
Control Functions of Mechanism
69
4
Fuel Filler Cap
The fuel filler cap can be seen after opening the seat
pad.
Warning
In order to prevent fire risks caused by fuel overflow
from the Fuel Inlet, make sure the Fuel Tank Cap is fully
locked after refueling.
Open the fuel filler cap by lifting upwards, then twist to
the left to open the cap.
Close the outer cover of the Gasoline Tank and then
screw back the Gasoline Tank cover. After confirming
that the Gasoline Tank cover is correctly restored, press
the Gasoline Tank outer cover until it is latched securely.
Locked
Open

KYMCO CV3 Series Specifications

General

Displacement	550.4 cc
Front Suspension	Telescopic fork
Rear Tire	160/60-15
Fuel Capacity	15.5 liters (4.1 gallons)
ABS	Yes
Max Power	51 hp @ 7500 rpm
Fuel System	Electronic fuel injection
Transmission	CVT
Front Brake	Dual disc
Rear Brake	Single disc
Weight	280 kg
Seat Height	795 mm
Max Torque	53 Nm @ 5750 rpm
Front Tire	120/70-15
