2LV/2L1/2L2/2MS/2MT
1-1-5
Figure 1-1-2
15
14
21
13
19
16
18
12
16
17
20
12. Operation panel
13. MP (multi purpose) tray
14. MP middle tray
15. MP top tray
16. MP Paper width guides
17. MP paper feed roller
18. Left cover
19. Waste toner box
20. Top tray (facedown)
21. Eject roller
