2LV/2L1/2L2/2MS/2MT
1-1-4
1-1-2 Parts names
(1) Machine (front side)
Figure 1-1-1
1
5
9
5
2
7
10
6
3
11
4
8
1. Machine
2. Power switch
3. Cassette
4. Paper size label
5. Paper width guides
6. Paper length guide
7. USB memory slot
8. Top cover
9. Toner container
10. Lock lever (Toner container)
11. Developer unit
