2PK/2PL/2PM/2PN
1-3-89
Test Page Printing a test page
Description
The halftones of sixteen different levels are printed for test.
Purpose
The developmental time of image error, the test print is performed for judgement of the
engine-side or the scanner-side.
Method
1. Enter the Service Setting menu.
2. Select [Test Page].
3. Press the start key.
4. Press [Yes] (the Left Select key). Test page will be printed.
Figure 1-3-20
Completion
Press the stop key.
New Developer Perform the toner installation of the developer unit.
Description
Perform the toner installation when the developer unit has been replaced.
Purpose
Perform when the developer unit is replaced.
Method
1. Enter the Service Setting menu.
2. Select [New Developer] using the cursor up/down keys.
3. Press [Yes] in the confirmation display.
Completion
Press the stop key.
Service items Description
Gray scale
(16 levels)
To Next Page
