2PK/2PL/2PM/2PN
1-5-39
8. Check or replace the control PWB and
refit all the removed parts.
To replace the control PWB, remove the
EEPROM (U17) from the old control
PWB and mount it to the new control
PWB.
Figure 1-5-58
U17
(EEPROM)
Control PWB
