2PK/2PL/2PM/2PN
2-3-10
YC25 1 +24V0IL I 24 V DC 24 V DC power source
Connected to
the high volt-
age PWB
2 +24V0IL I 24 V DC 24 V DC power source
3 PGND - - Ground
4 PGND - - Ground
YC26 1 +3.3V1E O 3.3 V DC 3.3 V DC power source
Connected to
the toner
sensor
2 TEMPTY I 0/3.3 V DC Toner quantity detection signal
3 SGND - - Ground
YC27 1 +24V0 O 24 V DC 24 V DC power source
Connected to
the right cool-
ing fan motor
2 FAN O 0/24 V DC Right cooling fan motor: On/Off
YC28 1 ERASER O 0/24 V DC Eraser lamp: On/Off
Connected to
the eraser
lamp
2 ERASRW O 24 V DC 24 V DC power source
YC29 1 DUDR1 O 0/24 V DC Duplex solenoid (activate): On/Off
Connected to
the duplex
solenoid
2 COMMON O 24 V DC 24 V DC power source
3 DUDR2 O 0/24 V DC Duplex solenoid (return): On/Off
YC30 1 +24V4IL O 24 V DC 24 V DC power source
Connected to
the optional
paper feeder
(PF main
PWB)
2 PGND - - Ground
3 PFSI I 0/3.3 V DC (pulse) Serial communication data input signal
4 PFSO O 0/3.3 V DC (pulse) Serial communication data output signal
5 PSEL O 0/3.3 V DC Paper feeder selection signal
6 +3.3V1 O 3.3 V DC 3.3 V DC power source
YC32 1 POWERSW I 0/3.3 V DC Power switch: On/Off
Connected to
the power
switch
2 NC - - Not used
3 GND - - Ground
Connector Pin Signal I/O Voltage Description
To Next Page
