2PK/2PL/2PM/2PN
2-4-17
Adjusting the scanning position for originals from the DP (alternative command for the maintenance
mode U068)
Description
Adjusts the position for scanning originals from the DP. Performs the test copy at the four scanning positions
after adjusting.
Purpose
Used when the image fogging occurs because the scanning position is not proper when the DP is used. Exe-
cute KCFG “EESS”,4, 107, 1, “#1”; command to adjust the timing of DP leading edge when the scanning posi-
tion is changed.
Example: DP READ set to 15, BLACK LINE set to 3
!R! KCFG “SCAN”,9,1,15; KCFG “SCAN”,9,2,3;EXIT;
Format !R! KCFG “SCAN”,9, #1,#2;EXIT;
Parameter #1 1: DP READ Starting position adjustment for scanning originals
2: BLACK LINE Scanning position for the test copy originals
#2 #1=1: Adjustable range: -33 to 33 (in 0.086mm increment) (0: default)
#1=2: Adjustable range: 0 to 3 (in 0.22mm increment) (0: default)
To Next Page
