2PK/2PL/2PM/2PN
1-3-64
U650 Setting modem 1
Description
Sets the G3 cable equalizer. Sets the modem detection level.
Purpose
Perform the following adjustment to make the equalizer compatible with the line characteristics.
To improve the transmission performance when a low quality line is used.
Method
1. Press the start key.
2. Select the item to be set using the cursor up/down keys.
Setting the G3 transmission cable equalizer
1. Select [0dB], [4dB], [8dB] or [12dB] using the cursor up/down keys.
* : Initial setting: 0dB
2. Press the start key. The setting is set.
Setting the G3 reception cable equalizer
1. Select [0dB], [4dB], [8dB] or [12dB] using the cursor up/down keys.
* : Initial setting: 0dB
2. Press the start key. The setting is set.
Setting the modem detection level
1. Select [33dBm], [38dBm], [43dBm] or [48dBm] using the cursor up/down keys.
* : Initial setting: 43dBm
2. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
REG. G3 TX EQR Sets the G3 transmission cable equalizer.
REG. G3 RX EQR Sets the G3 reception cable equalizer.
RX MODEM LEVEL Sets the modem detection level.
To Next Page
