Kyocera ECOSYS P4140dn User Manual

8-26
Setup and Registration (System Menu) > System Menu
Optional Network
Configure settings for the optional Network Interface Kit or Wireless Network Interface Kit.
Wireless Network
[Menu] key > [▲] [▼] key > [Optional Network] > [OK] key > [▲] [▼] key > [Wireless Network] > [OK] key
NOTE
This menu is displayed when the optional Network Interface Kit or Wireless Network Interface Kit is installed.
NOTE
This function is displayed when the optional Wireless Network Interface Kit is installed.
Item Description
ConnectionStatus When the optional Wireless Network Interface Kit is installed, you can check the wireless LAN status.
Quick Setup If the machine will connect to an access point that supports the automatic wireless network setup,
connection settings can be configured by Quick Setup.
AvailableNetwork Displays access points to which the machine can connect.
Push Button If the access point supports the push button method, wireless settings can be configured using
the push button. This setting executes push button, and the connection is started by pressing
the push button on the access point.
NOTE
The push button method supports only the WPS.
PIN (Device) Starts connection using the machine's PIN code. Enter the PIN code into the access point. The
PIN code of the machine is automatically generated.
PIN (Terminal) Starts connection using the PIN code of the access point. Enter the PIN code of the access point.
Custom Setup The detailed settings for wireless LAN can be changed. You can check the connection with a
wireless network by selecting [Connect].
Netwk Name(SSID) Set the SSID (Service Set Identifier) of the wireless LAN to which the machine connects.
NOTE
Up to 32 characters can be entered.
Connection Mode Set the connection mode.
Value: Ad
Hoc, Infrastructure
NOTE
Ad Hoc: Directly communicates with the device without going through an access point. This
method cannot be used to connect to two or more devices.
Infrastructure: Performs communication through an access point.
Channel Set channel. Use [▲] or [▼] or the numeric keys to enter a number.
Value: 1 to 11
Netwk Authentic. Select network authentication type. To select other options, open the device home page from a
computer.
Value: Open, Shared, WPA-PSK
*1
, WPA2-PSK
*1

Kyocera ECOSYS P4140dn Specifications

General

Display	LCD
Control type	Buttons
Certification	TÜV, GS, CE
Color display	No
Product color	Black, White
Built-in display	Yes
Market positioning	Business
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.3 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	28 ppm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1415 W
Power consumption (off)	0.5 W
Power consumption (ready)	15 W
Power consumption (standby)	11 W
Power consumption (printing)	632 W
Energy Star Typical Electricity Consumption (TEC)	1.9 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks
PCL fonts	93
Printer fonts	Barcode, Bitmap, PCL
Printing colors	Black
Country of origin	Vietnam
Maximum duty cycle	150000 pages per month
Recommended duty cycle	10000 - 15000 pages per month
Replacement cartridges	TK-7310 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, JPEG, OpenXPS, PCL 5c, PCL 6, PDF 1.7, TIFF, XPS
Linear (1D) barcodes supported	EAN 128, EAN-13, EAN-8, PDF417
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	Blue Angel, ENERGY STAR
Total input capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Package depth	542 mm
Package width	581 mm
Package height	460 mm
Package weight	26000 g
Cables included	AC
Included cartridge capacity (black)	7500 pages
Envelopes sizes	C5, DL
Custom media width	70 - 148 mm
Maximum print size	297 x 432 mm
Custom media length	297 - 1220 mm
Paper tray media types	Plain paper, Thick paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A4+, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	2
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Harmonized System (HS) code	84433210
Processor model	A9
Processor family	ARM Cortex
Maximum internal memory	2500 MB
Sound pressure level (printing)	50.7 dB
Sound pressure level (quiet mode)	47.9 dB

Weight and Dimensions

Depth	410 mm
Width	477 mm
Height	343 mm
