2-5

Installing and Setting up the Machine > Part Names

With Optional Equipments Attached

1 Cassette 2

2 Cassette 3

3 Cassette 4

4 Cassette 5

5 Caster kit

6 Paper Stopper

7 Rear Tray

Optional Equipment (page 11-2)
