Kyocera ECOSYS P4140dn User Manual

10-16
Troubleshooting > Troubleshooting
C
Message Checkpoints Corrective Actions
Reference
Page
Canceling... ― Displayed when data is being
canceled.
―
Cannot connect. ― This appears when the Wi-Fi or Wi-
Fi Direct connection did not
complete. Check the settings, and
check the signal conditions.
page 7-5
Cannot connect to
Authentication Server.
― Press [OK] and check the following
items:
• Registration to Authentication
Server
• Password and computer address for
A
uthentication Server
• Connection of Network
page 9-3
Cannot connect to the
network.
Check the network.
― Unable to connect to the optional
network. Check the optional
network settings.
page 8-26
Cannot connect.
Multiple access points
a
re enabled.
― Is the push button on the multiple
access poi
nts pressed
simultaneously?
Specify an access point which you
want to use. and press the push
button again.
Retry the connection by specifying
an access point after waiting for a
while.
―
Cannot duplex print on
this paper.
*1
Did you select a paper size/type
that cannot be duplex printed?
Select [Alt] to select the available
paper. Select [Continue] to print
without using Duplex function.
Select [Cancel] to cancel the job.
―
Cannot execute this job.
Restricted by
Authentication settings.
― This job is canceled because it is
restricted by Group Authentication
settings. Select [OK].
―
Cannot perform. ― It is not possible to perform
sanitization because a job is being
processed, etc.
―
Cannot recognize. ― Make sure your ID card has been
registered.
page 9-11
Cannot recognize ID
card.
― Make sure the USB connector of
the ID card reader is correctly
connected to the machine.
If USB Host is set to [Block],
change the setting to [Unblock].
page 8-35
Cannot remove the
memory while in use.
― This message is displayed when
[Remove USB Drive] was selected
while a USB drive was being used.
The previous screen is displayed
ag
ain 1 or 2 seconds.
page 5-13
Cassette# not loaded. ― The corresponding paper cassette
is not installed. Install the cassette.
page 3-4

Kyocera ECOSYS P4140dn Specifications

General

Display	LCD
Control type	Buttons
Certification	TÜV, GS, CE
Color display	No
Product color	Black, White
Built-in display	Yes
Market positioning	Business
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.3 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	28 ppm
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1415 W
Power consumption (off)	0.5 W
Power consumption (ready)	15 W
Power consumption (standby)	11 W
Power consumption (printing)	632 W
Energy Star Typical Electricity Consumption (TEC)	1.9 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks
PCL fonts	93
Printer fonts	Barcode, Bitmap, PCL
Printing colors	Black
Country of origin	Vietnam
Maximum duty cycle	150000 pages per month
Recommended duty cycle	10000 - 15000 pages per month
Replacement cartridges	TK-7310 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, JPEG, OpenXPS, PCL 5c, PCL 6, PDF 1.7, TIFF, XPS
Linear (1D) barcodes supported	EAN 128, EAN-13, EAN-8, PDF417
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	Blue Angel, ENERGY STAR
Total input capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Package depth	542 mm
Package width	581 mm
Package height	460 mm
Package weight	26000 g
Cables included	AC
Included cartridge capacity (black)	7500 pages
Envelopes sizes	C5, DL
Custom media width	70 - 148 mm
Maximum print size	297 x 432 mm
Custom media length	297 - 1220 mm
Paper tray media types	Plain paper, Thick paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A4+, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	2
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Harmonized System (HS) code	84433210
Processor model	A9
Processor family	ARM Cortex
Maximum internal memory	2500 MB
Sound pressure level (printing)	50.7 dB
Sound pressure level (quiet mode)	47.9 dB

Weight and Dimensions

Depth	410 mm
Width	477 mm
Height	343 mm
