20
Jam Inside the Printer
1 Open the printer’s top cover.
2 Open the printer’s front cover.
3 Lift the process unit together with the
toner container out of the printer.
4 Remove the jammed paper.
When pulling the paper, pull
gently so as not to tear it. Torn
pieces of paper are difficult to
remove and may be easily over-
looked, preventing recovery
from the jam.
5 Replace the process unit and toner con-
tainer, then close the printer.
To p co v e r
Front Cover
Process Unit
Ifs1020ep-eng.book 20 ページ ２００３年９月３日 水曜日 午後４時４７分
To Next Page
