Kyocera FS-1030MPF

2MH/2MJ/2MK/2ML
1-2-3
(2) Removing the tapes
<Procedure>
1. Remove two tapes.
2. Open the sheet.
Figure 1-2-3
3. Remove two tapes A.
4. Open the top cover.
5. Remove the tape B and then remove
the spacer.
6. Close the top cover.
Figure 1-2-4
Sheet
Tape
Tape
Sheet
Tape B
Tape A
Top cover
Tape A
Spacer
