Kyocera FS-1128MFP Setup Guide

Accessing COMMAND CENTER
SETUP GUIDE 17
3
Click Submit.
E-mail Settings
The following procedure explains the method for attaching scan data to e-mail for
transmission. Scan to e-mail works within the following environments:
• It must have a network environment in which this machine can connect to a
mail server. It is recommended that the machine be used in an environment in
which it can connect to the mail server at any time over a LAN.
• The SMTP settings must be completed. Use COMMAND CENTER, to register
the IP address and the host name of the SMTP server.
• There may be a times where transmission is not possible due to the size of
each e-mail item.
The scanner system network component offers e-mail function. SMTP is an
embedded protocol to support this function. To use the e-mail function, the scanner
system needs connection to an e-mail server using the POP3 protocol.
IPv4 Settings
DHCP/BOOTP
Specifies whether or not to automatically obtain an IP address using DHCP or
BOOTP.
IP Address (IPv4) Assigns the Internet Protocol address on the printing system network component.
The format of the IP address is four-byte (32-bit) numbers separated by dots, e.g.
192.168.110.171.
Subnet Mask Specifies the subnet mask of the hosts or network with which the print system is
connecting. If you have manually assigned an IP address that starts with a number
between 192 and 223, it is recommended that you set the subnet mask to
"255.255.255.0."
Default Gateway Specifies the IP address of the default gateway.
IPv6 Settings
IPv6
Specifies whether or not to enable the IPv6 protocol. Select On to use the IPv6
protocol.
IP Address (IPv6) Assigns an IPv6 address to the printing system network component. The format of
the IPv6 address is a sequence of numbers (128 bit in total) separated by colons,
e.g. 2001:db8:3c4d:15::1a2c:1a1f.
Prefix Length Specifies the IPv6 prefix length of the hosts or network with which the print system
is connecting.
RA (Stateless) Select On to use RA to configure IPv6 addresses.
Default Gateway Specifies the IPv6 address of the default gateway.
DHCPv6 Specifies whether or not to obtain IPv6 IP addresses by automatic configuration.
When RA is turned On, the IP addresses and server information are obtained via
DHCPv6 based on the settings of the automatic configuration made under RA
(router setting).
Item Description

Kyocera FS-1128MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Scan to	FTP
Grayscale levels	256
Image formats supported	JPG, TIF
Optical scanning resolution	- DPI
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.9 s
Faxing	Mono faxing
Fax memory	100 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Internal memory	256 MB
Processor model	440
Processor family	PowerPC
Maximum internal memory	768 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	52 dB
Custom media sizes	105 x 148mm/216 x 356mm
Dimensions (WxDxH)	494 x 410 x 366 mm
Power requirements	AC 220 - 240 V, 50/60Hz
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows 2000/XP/Server 2000/Server 2003/ Vista/Server 2008, MAC OS 9.X, MAC OS X, Linux
Maximum print size	216 x 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	91 W
Power consumption (PowerSave)	10.2 W
Power consumption (average operating)	494 W
Certification	TÜV/GS, CE
Display	-
Market positioning	Business
Supported network protocols (IPv6)	SNMPv3, SSL, IPsec
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433100
