Kyocera FS-1128MFP Setup Guide

Sharing PC Folder
24 SETUP GUIDE
8
Add the user name displayed in the Group or user names. Click Add, then click
Locations. Select the computer to which the shared folder was created (Example:
PC4050) and then click OK.
9
Enter the user name added as a local user into the text box and click OK.
10
Select the added user, click the checkbox under Allow for Modify and Read, then
click OK.
11
Click OK to close the Properties dialog box.
Specifying Destination
Check the computer information required to enter on the touch panel when sending
a file. The information you require to check using the computer is:
• Entry for Host Name
• Entry for Path
• Entry for Login User Name
Checking the Entry for Host Name
Check the name of the destination computer.
1
Right-click My Computer and select Properties. The System Properties dialog
box appears.
2
Click the Computer Name tab to view the name of computer.
If the Computer Name tab contains Full computer name and Domain
The characters to the left of the first dot (.) in the Full computer name text box
correspond to the entry for Host Name. (Example: pc4050)

Kyocera FS-1128MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Scan to	FTP
Grayscale levels	256
Image formats supported	JPG, TIF
Optical scanning resolution	- DPI
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.9 s
Faxing	Mono faxing
Fax memory	100 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Internal memory	256 MB
Processor model	440
Processor family	PowerPC
Maximum internal memory	768 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	52 dB
Custom media sizes	105 x 148mm/216 x 356mm
Dimensions (WxDxH)	494 x 410 x 366 mm
Power requirements	AC 220 - 240 V, 50/60Hz
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows 2000/XP/Server 2000/Server 2003/ Vista/Server 2008, MAC OS 9.X, MAC OS X, Linux
Maximum print size	216 x 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	91 W
Power consumption (PowerSave)	10.2 W
Power consumption (average operating)	494 W
Certification	TÜV/GS, CE
Display	-
Market positioning	Business
Supported network protocols (IPv6)	SNMPv3, SSL, IPsec
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433100
