Kyocera FS-2020D Advanced Operation Guide

Using the Operation Panel 7-37
4 Press U or V to display the desired binding mode. The message
display toggles through the following:
Off (default)
Short edge bind
Long edge bind
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
Paper Output (Selecting the output stack)
The Paper Output menu on the operation panel allows you to select
either the face-down tray or the faceup tray option for the output stack.
1 Press Z while Print Settings > is displayed.
2 Press U or V repeatedly until >Paper Output appears.
3 To change the output stack, press [OK]. A blinking question mark (?)
appears.
4 Press U or V to select output stack - Top tray FaceDn or
RearTray FaceUp.
5 When the desired output stack is displayed, press [OK].
6 Press [MENU]. The display returns to Ready.
Override A4/LT (Overriding difference between A4
and Letter)
When the Override A4/LT is turned On using the operation panel, the
printer ignores the difference between A4 and Letter paper sizes.
Printing is performed without an error message even if the actual paper
size in the current cassette differs from the paper size formatting the job.
By default, this feature is On.
1 Press Z while Print Settings > is displayed.
2 Press U or V repeatedly until >Override A4/LT appears.
3 Press [OK]. A blinking question mark (?) appears.
4 Select On or Off using U or V.
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
Emulation (Setting the emulation)
You can change the emulation mode. Use the procedure below to select
the mode.
1 Press Z while Print Settings > is displayed.
Note This menu can be used for FS-3920DN and FS-4020DN.
>Paper Output
Top tray FaceDn
>Paper Output
?Top tray FaceDn
>Override A4/LT
? On

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
