Kyocera FS-C2626MFP Operation Guide

10-6
Troubleshooting > Error Code List
U03400 Polling reception was interrupted because the password entered by the other party did not match the
Local FAX ID on the receiving machine. Check with the other party.
U03500 Sub address bulletin board reception was attempted and the other party’s machine is an our brand
model, but the specified sub address box was not registered on the other party’s machine.
Check with the recipient.
U03600 The other party’s machine is an our brand model and sub address bulletin board reception was
interrupted because the specified sub address password was incorrect. Check with the other party.
U03700 Sub address bulletin board reception was attempted but the other party’s machine either does not
have a sub address bulletin board communication function or there were no originals in any of the
originals transfer boxes (sub address boxes).
U04000 Specified sub address box is not registered in our brand recipient machine, or the sub address does
not match.
U04100 Recipient machine is not equipped with a sub address box function, or the sub address does not
match.
U04200 Encrypted transmission was canceled because the specified box is not registered.
U04300 Encrypted transmission was canceled because the recipient fax is not equipped with an encrypted
communication function.
U04400 Encrypted transmission was canceled because the encryption key does not match.
U04500 Encrypted reception was canceled because the encryption key does not match.
U05100 Transmission was canceled because communication requirements are not met due to the
transmission restriction set on this machine. Check with the recipient.
U05200 Reception was canceled because communication requirements are not met due to the reception
restriction set on this machine.
U05300 Reception was rejected by the recipient because communication requirements are not met due to the
reception restriction set on the recipient machine. Check with the recipient.
U14000 Reception to the Sub Address Box was stopped because there is no more free space in the memory of
this machine. Create free space by outputting the data stored in the memory, or cancel the reception to
the Sub Address Box.
U14100 Transmission to the Sub Address Box or sub address box on our brand recipient machine was
stopped because there is no more free space in the memory of the recipient machine. Check with the
recipient.
U19000 Memory reception was stopped because there is no more free space in the memory of this machine.
Create free space by outputting the data stored in the memory, and ask the sender to resend.
U19100 Transmission was stopped because there is no more free space in the memory of the recipient
machine. Check with the recipient.
U19300 Transmission was stopped due to a data error occurring during transmission. Send again.
Error Code Possible Cause/Action

Kyocera FS-C2626MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10 s
Time to first copy (color, normal)	12 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	35 inch/min
Scan speed (color)	25 inch/min
Image formats supported	JPG, TIF
Document formats supported	PDF
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MR
Fax transmission speed	3 sec/page
Fax speed dialing (max numbers)	100
Paper input type	Cassette, Paper tray, Sheetfed
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	1350 sheets
Total number of input trays	3
Maximum number of input trays	7
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	No
Mobile printing technologies	Not supported
Processor model	464
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	76 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	475 W
Sustainability certificates	ENERGY STAR
Certification	TUV, GS, CE
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012

Weight and Dimensions

Depth	550 mm
Width	514 mm
Height	603 mm
