Options
3-7
Removing a Memory Module
To remove a memory module, carefully pull the end
clips outwards, then pull the memory module out of the
socket.
Testing the expanded memory
After you finish installing DIMMs in the printer, test the printer to see if the installation was
successful. To test the expansion memory, proceed as follows:
1
Make sure the printer is turned off. Plug the power cord into the printer and turn the printer on.
2
Press [Menu] on the operation panel.
3
Press or repeatedly until Print Status Page appears.
4
Press [OK] twice.
5
If the installation was successful, the amount of memory shown on the status page will correspond
with the amount of expanded memory. (The factory installed memory size is 256 MB.)
