4-116 Using the Operation Panel
Drum (Drum/Refresh mode setting)
This sets the refresh mode for the drum. When the printing quality
declines, refreshing the drum can restore the printing quality. This is
primarily used for maintenance by service personnel.
1 In the Service Setting menu, press U or V to select Drum.
2 Press [OK]. A confirmation screen appears.
Press [Yes] ([Left Select]). Carry out drum refresh.
Pressing [No] ([Right Select]) returns you to the Service Setting.
menu screen without refreshing the drum.
LSU (LSU cleaning mode setting)
This sets the cleaning mode for the LSU. When the printing quality
declines, cleaning the LSU can restore the printing quality. This is
primarily used for maintenance by service personnel.
1 In the Service Setting menu, press U or V to select LSU.
2 Press [OK]. A confirmation screen appears.
Press [Yes] ([Left Select]). Carry out the LSU cleaning.
Pressing [No] ([Right Select]) returns you to the Service Setting
menu screen without cleaning the LSU.
MP Tray Cleaning (MP Tray Cleaning mode setting)
If dirt appears on images when using the MP tray, perform MP Tray
Cleaning.
1 In the Service Setting menu, press U or V to select MP Tray
Cleaning.
2 Press [OK]. A confirmation screen appears.
3 Load two sheets of A4 or Letter paper in the MP tray.
4 Press [Yes] ([Left Select]). MP Tray Cleaning starts.
Pressing [No] ([Right Select]) returns you to the Service Setting
menu screen without performing MP Tray Cleaning.
Silent Mode (Silent Mode setting)
Make the machine run more quietly. Select this mode when the running
noise is uncomfortable. Use the procedure below to set Silent mode.
1 In the Service Setting menu, press U or V to select Silent Mode.
2 Press [OK]. The Silent Mode screen appears.
3 Press U or V to select the Silent Mode.
4 Press [OK]. The Service Setting menu reappears.
Drum
Are you sure?
[ Yes ] [ No ]
LSU
Are you sure?
[ Yes ] [ No ]
Start the MP tray
cleaning.
Are you sure?
[ Yes ] [ No ]
Silent Mode a b
1 *Off
2 On

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
