Kyocera FS-C8500DN

1-4 Machine Parts
Internal Components
23 Black Toner Container (K)
24 Black Toner Container (K) Release Lever
25 Yellow Toner Container (Y)
26 Yellow Toner Container (Y) Release Lever
27 Cyan Toner Container (C)
28 Cyan Toner Container (C) Release Lever
29 Magenta Toner Container (M)
30 Magenta Toner Container (M) Release Lever
31 Cleaning Brush
32 Waste Toner Box
33 Waste Toner Tray
34 Release button
35 Paper Feed Unit Cover
36 Paper Feed Unit
37 Green Knob
38 Paper Width Adjusting Tab
39 Paper Length Guide
31
23 24 26 28 3025 27 29
32
33 34
38
39
37
36
35
