Kyocera FS-C8500DN User Manual

iii
Contents
Legal and Safety Information
1 Machine Parts
Components at the Front of the Printer ................................... 1-2
Components at the Left of the Printer ...................................... 1-2
Components at the Right of the Printer ................................... 1-3
Internal Components .................................................................. 1-4
Operation Panel .......................................................................... 1-5
2 Printing Operation
Changing Network Interface Parameters ................................. 2-2
Printing a Status Page ............................................................... 2-3
Installing the Printer Driver ....................................................... 2-4
Printing from Application Software .......................................... 2-9
Status Monitor .......................................................................... 2-10
Uninstalling Software (Windows PC) ...................................... 2-13
3 Handling Paper
General Guidelines ..................................................................... 3-2
Selecting the Right Paper .......................................................... 3-4
Special Paper .............................................................................. 3-7
Paper Type ................................................................................ 3-12
Loading Paper ........................................................................... 3-13
4 Using the Operation Panel
General Information ................................................................... 4-2
Understanding the Operation Panel ......................................... 4-3
Keys ............................................................................................. 4-6
Using the Menu Selection System ............................................ 4-8
Setting a Mode Selection Menu ............................................... 4-10
Report Print ............................................................................... 4-11
USB Memory (USB memory selection) ................................... 4-16
Custom Box .............................................................................. 4-22
Job Box ..................................................................................... 4-28
Job Log ...................................................................................... 4-42
Counter (Viewing the counter value) ...................................... 4-44
Paper Settings .......................................................................... 4-46
Print Settings ............................................................................ 4-55
Network (Network settings) ..................................................... 4-65
Device Common (Selecting/Setting the common device) .... 4-72
Security (Security function setting) ........................................ 4-85
Job Account.Set. (Job Account setting) ................................ 4-94
Administrator (Administrator settings) ................................ 4-102
Adjust/Maint. (Adjust/Maintenance selection/setting) ........ 4-105
5 Maintenance
General Information ................................................................... 5-2
Toner Container Replacement .................................................. 5-2
Replacing the Waste Toner Box ................................................ 5-6
Cleaning the Printer ................................................................... 5-8
6 Troubleshooting
General Guidelines ..................................................................... 6-2
Print Quality Problems ............................................................... 6-3
Error Messages ........................................................................... 6-5
Clearing Paper Jams ................................................................ 6-15

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
