Kyocera FS-C8500DN

1-2 Machine Parts
Components at the Front of the Printer
1 Operation Panel
2USB Memory Slot
3 Front Cover
4 Paper Cassette 1
5 Paper Cassette 2
6 Top Cover
7Top Tray
8 Paper Stopper
Components at the Left of the Printer
9 Left Cover 1
10 Left Cover 1 Indicator
11 Left Cover 1 Lever
12 Left Cover 2 Indicator
13 Left Cover 2
14 Left Cover 3
15 Handles
5
1
2
3
4
8
6
7
9
10
11
12
13
14
15
