1-5
1. Procedure for Installing and Printing with a Printer Driver
Select the driver type.
From the list, select the type of driver to be installed, then click Next.
* Refer to “1-1 Included printer Drivers” on page 1-1 for information regarding each
printer driver.
Select the connection type: Local or Network.
• Local: The printer is connected directly to the parallel port.
• Network: The printer is connected to the printer via network (using a network
interface).
* If Local is selected, proceed to step 11. If Network is selected, proceed to step
10.
Enter the network queue name or the path for the network queue in the box.
To select another network queue name, press Browse.
If you are going to use a local port for the network queue, click the check box
displayed below, then proceed to step 11.
Otherwise, proceed to step 12.
All available options will be displayed. Select the items that you want to install and
then click on the [Next] button.
7
8
9
10
To Next Page
