Part Names
1-6
23 Paper Length Guide
24 (Paper Width Guide) Lock
25 Inner Tray
26 USB Port (A1)
27 Right Cover 1 Lever
28 Right Cover 1
29 Main Power Switch
30 Paper Width Adjusting Tab
31 Handle
32 Right Cover 2 Lever
33 Right Cover 2
34 Paper Width Guide
35 Support Tray Section of the Multi Purpose Tray
36 Multi Purpose Tray
37 Right Cover 3 Lever
38 Right Cover 3
