9-25
User Authentication and Accounting (User Login, Job Accounting) > Setting User Login Administration
Obtain NW User Property
Set the required information to obtain the network user property from the LDAP server. The user name and E-mail
address obtained with this setting is shown in the user information, the status confirmation screen, and the header of
E-mail.
1
Display the screen.
1 [System Menu/Counter] key > [User Login/Job Accounting]
2 [User Login Setting] > [Obtain NW User Property] > [On]
2
Configure the settings.
[On] > Add information on each item > [OK]
To obtain the network user property from the LDAP server, [Network Authentication] must be selected for the
authentication method in "Enabling User Login Administration". Select "On" for "LDAP" in "Protocol Detail".
Enabling User Login Administration (page 9-3)
Protocol Settings (page 8-53)
If the login user name entry screen appears during operations, enter a login user name
and password, and select [Login]. For this, you need to login with administrator
privileges.
The factory default login user name and login password are set as shown below.
Item Descriptions
Server Name
*1
Enter the LDAP server name or the IP address (up to 64
characters). If a server name is not entered, user information will
be acquired from the server set for Network Authentication.
Port Port number for LDAP server. The default port number is 389.
Name 1
*2
Enter the LDAP Attribute to obtain the user name to be displayed
from the LDAP server (up to 32 characters).
Name 2
*3
Enter the LDAP Attribute to obtain the user name to be displayed
from the LDAP server (up to 32 characters).
E-mail Address
*4
Enter the LDAP Attribute to obtain the E-mail address from the
LDAP server (up to 32 characters).
Authentic at Type
*5
Set the authentication method. Select [Simple] or [SASL]. After
changing the setting, restart the system or turn the power off and
then on.
Model Name Login User Name Login Password
3212i 3200 3200
4012i 4000 4000
