Kyocera TASKalfa 4012i - Part Names (Connectors;Interior)

To Next Page

To Previous Page

2-4

Installing and Setting up the Machine > Part Names (Connectors/Interior)

Part Names (Connectors/Interior)

1 USB Interface Connector

2 USB Port

3 Network Interface Connector

4 Option Interface Slot

5 Toner Container

6 Waste Toner Box

7 Spare Waste Toner Box Tray (W1)
