Kyocera TASKalfa 4012i - Part Names (With Optional Equipments Attached)

2-5
Installing and Setting up the Machine > Part Names (With Optional Equipments Attached)
Part Names (With Optional Equipments
Attached)
1 Tray 1 to 7 (tray 1 is the top tray)
2 Tray A
3 Tray B
4 Job Separator Tray
5 Finisher Tray
Optional Equipment (page 11-2)
6 Cassette 3
7 Cassette 4
8 Control Section of the Finisher
Manual Staple (page 5-70)
9 Original Cover
1
6
9
76
2
3
4
8
5
7
