Kyocera TASKALFA FS-1100 Service Manual

2KL/2KK
1-3-42
U203
Checking DP separately
Description
Simulates the original conveying operation separately in the DP.
Purpose
To check the DP operation.
Method
1. Press the start key.
2. Place an original on the DP if running this simulation with paper.
3. Select the item to be operated using the exposure adjustment keys.
4. Press the start key. The operation starts.
5. To stop continuous operation, press the stop/clear key.
Completion
Press the stop/clear key when the operation stops. The screen for selecting a maintenance item No. is dis-
played.
U204
Setting the presence or absence of a key card or key counter
Description
Sets the presence or absence of the optional key card or key counter.
Purpose
To run this maintenance item if a key card or key counter is installed.
Setting
1. Press the start key.
2. Select the item using the zoom +/- keys.
Initial setting: oFF
3. Press the start key. The setting is set.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
U207
Checking the operation panel keys
Description
Checks operation of the operation panel keys.
Purpose
To check operation of all the keys and LEDs on the operation panel.
Method
1. Press the start key.
2. "1" appears on the copy quantity display and the leftmost LED on the operation panel lights.
3. As the keys on the operation panel are pressed in order from the left to right, the figure shown on the
copy quantity display increases in increments of 1. If there is an LED corresponding to the key pressed,
the LED will light.
4. When all the keys on the operation panel have been pressed, all the LEDs light for up to 10 seconds.
5. When the LEDs go off, press the start key. All the LEDs light for 10 seconds again.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Exposure indicator Display Motor
Exp. 1 d-P With paper
Exp. 2 d-n Without paper (continuous operation)
Exp. 3 dp2 With paper (duplex mode)
Exp. 4 dn2 Without paper (duplex mode)
Display Description
oFF None
Crd The key card is installed
Cnt The key counter is installed
