―5―
３−１ KEWSNAP 2002PA
●Measuring Ranges and Accuracy(at 23±5℃, relative humidity 45-75%)
AC Current
〜
400Ａ，
〜
2000Ａ
３．Specifications
Range
400Ａ
2000Ａ
Measuring Range
０〜400.0Ａ
０〜1000Ａ
1000〜1500Ａ
1500〜2000Ａ
Measuring Range
０〜40.00Ｖ
15.0〜400.0Ｖ
150〜750Ｖ
Measuring Range
０〜±40.00Ｖ
±15.0〜±400.0Ｖ
±150〜±1000Ｖ
Measuring Range
０〜400.0Ω
0.150〜4.000kΩ
1.50〜40.00kΩ
15.0〜400.0kΩ
Output Voltage / Measuring Range
０〜400.0ｍＶ /０〜400Ａ
０〜150.0ｍＶ /０〜1500Ａ
150.0〜200.0ｍＶ/1500〜2000Ａ
Resolution
0.1Ａ
１Ａ
Resolution
0.01Ｖ
0.1Ｖ
１Ｖ
Resolution
0.01Ｖ
0.1Ｖ
１Ｖ
Resolution
0.1Ω
１Ω
10Ω
100Ω
Accuracy（Frequency Range）
±1.0％rdg±3dgt(50/60Hz）
±2.0％rdg±3dgt(40〜１kHz)
±1.0％rdg±3dgt(50/60Hz）
±3.0％rdg±3dgt(40〜１kHz)
±3.0％rdg (50/60Hz）
Accuracy（Frequency Range）
±1.0％rdg±2dgt(50/60Hz）
±1.5％rdg±3dgt(40〜１kHz)
Accuracy
±1.0％rdg±2dgt
Accuracy
±1.5％rdg±2dgt
Accuracy（Frequency Range）
±1.5％rdg±0.5ｍＶ(50/60Hz）
±2.5％rdg±0.5ｍＶ(40〜１kHz）
±1.5％rdg±0.5ｍＶ(50/60Hz）
±3.5％rdg±0.5ｍＶ(40〜１kHz）
±3.5％rdg (50/60Hz）
Maximum Measurement Time
Continuous
15min
５min
Range
40Ｖ
400Ｖ
750Ｖ
Range
40Ｖ
400Ｖ
1000Ｖ
Range
400Ω
4kΩ
40kΩ
400kΩ
Range
400Ａ
2000Ａ
AC Voltage（〜Ｖ）Auto-ranging
Initially set to the 40V range. Input impedance is about 1MΩ.
DC Voltage（Ｖ）Auto-ranging
Initially set to the 40V range. Input impedance is about 1MΩ.
Resistance(Auto-ranging)
Initially set to the 400Ω range. In the continuity check mode, fixed to the 400Ω range and
when the reading is not more than 50±35Ω, the buzzer beeps.
ＯＵＴＰＵＴ（AC Current Ranges）
DC Output: 100.0mV per 1000 counts (Output impedance: about 10kΩ)
●
Electromagnetic compatibility (EMC)
EN61000-4-3 Radiated RF electromagnetic field immunity
RF field strength
＝
＜
＝１Ｖ／ｍ
, total accuracy
：
specified accuracy
RF field strength
＝３Ｖ／ｍ
, total accuracy
：
specified accuracy
＋２％
of range
