３−２ KEWSNAP 2002R
●Measuring Ranges and Accuracy(at 23±5℃, relative humidity 45-75%)
AC Current
〜
400Ａ，
〜
2000Ａ (9 counts or less is corrected to 0)
Range
400Ａ
2000Ａ
Measuring Range
０〜400.0Ａ
０〜1000Ａ
1000〜1500Ａ
1500〜2000Ａ
Measuring Range
０〜40.00Ｖ
15.0〜400.0Ｖ
150〜750Ｖ
Measuring Range
０〜±40.00Ｖ
±15.0〜±400.0Ｖ
±150〜±1000Ｖ
Measuring Range
０〜400.0Ω
0.150〜4.000kΩ
1.50〜40.00kΩ
15.0〜400.0kΩ
Output Voltage / Measuring Range
０〜400.0ｍＶ /０〜400Ａ
０〜150.0ｍＶ /０〜1500Ａ
150.0〜200.0ｍＶ/1500〜2000Ａ
Resolution
0.1Ａ
１Ａ
Resolution
0.01Ｖ
0.1Ｖ
１Ｖ
Resolution
0.01Ｖ
0.1Ｖ
１Ｖ
Resolution
0.1Ω
１Ω
10Ω
100Ω
Accuracy（Frequency Range）
±1.5%rdg±3dgt（45〜65Hz）
±2.5%rdg±3dgt（40〜1kHz）
±2.0%rdg±5dgt（45〜65Hz）
±3.0%rdg±5dgt（40〜1kHz）
±4.0%rdg （50/60Hz）
Accuracy（Frequency Range）
±1.0％rdg±2dgt(45〜65Hz)
±1.5％rdg±3dgt(40〜１kHz)
Accuracy
±1.0％rdg±2dgt
Accuracy
±1.5％rdg±2dgt
Accuracy（Frequency Range）
±2.0%rdg±0.5mV（45〜65Hz）
±3.0%rdg±0.5mV（40〜1kHz）
±2.5%rdg±0.5mV（45〜65Hz）
±3.5%rdg±0.5mV（40〜1kHz）
±4.5%rdg （50/60Hz）
Maximum Measurement Time
Continuous
15min
５min
Range
40Ｖ
400Ｖ
750Ｖ
Range
40Ｖ
400Ｖ
1000Ｖ
Range
400Ω
4kΩ
40kΩ
400kΩ
Range
400Ａ
2000Ａ
AC Voltage（
〜
Ｖ）Auto-ranging (9 counts or less is corrected to 0)
Initially set to the 40V range. Input impedance is about 1MΩ.
When approx.300V or more is applied to the instrument instantaneously, the measured
value is indicated on 750V range.
DC Voltage（Ｖ）Auto-ranging
Initially set to the 40V range. Input impedance is about 1MΩ.
Resistance(Auto-ranging)
Initially set to the 400Ω range. In the continuity check mode, fixed to the 400Ω range and
when the reading is not more than 50±35Ω, the buzzer beeps.
ＯＵＴＰＵＴ（AC Current Ranges）
DC Output: 100.0mV per 1000 counts (Output impedance: about 10kΩ)
●
CF (Crest Factor) CF=3 or less
accuracy+1% (45
〜
65Hz)
、
less than AC3000A/AC1200V Peak
●
Electromagnetic compatibility (EMC)
EN61000-4-2 Electrostatic discharge immunity(ESD)
Performance criteria B
