21

4. Display examples of DAR/ PI values
The DAR/PI values are displayed as follows during a
measurement.
5. How to review the measured DAR/ PI values
Press the DISP button after a measurement. The measured
results are then displayed in the following sequence. If a
measurement ends earlier than the intervals described in
below(2),(3)or(4),nothingwillbedisplayedandreturnsto
theinitialstate(1).
(1) Start of test
No DAR/PI value,
“---” is displayed.
DAR value is displayed.
PI value is displayed.
Press the DISP button to switch
DAR and PI values.
(2) 1 min after the start of test
(3) 10 min after the start of test
www.calcert.com sales@calcert.com1.888.610.7664
0
5
10
15
20
25
30
