*KEW3125Ahasanadditionalrange.
Rated
voltage
5000V
Measuring
Range(*1)
0.0-99.9MΩ
80-999MΩ
0.80-9.99GΩ
8.0-99.9GΩ
80-1000GΩ
Display
range
0.0M-1200GΩ
Opencircuit
Voltage
DC5000V
Rated
Current
1mAormore,
1.2mAorless
(at5MΩload)
Short-circuit
Current
1.5mA±0.5mA
Accuracy ±5%rdg±3dgt ±20%
Voltagemonitorforinsulationresistancerange
KEW3125A:30-6000V(resolution10V):±10%rdg±20V
KEW3025A:30-3000V(resolution10V):±10%rdg±20V
Thismonitorisusedtocheckwhetherelectricchargesstored
ontheequipmentundertestaredischargedornot.Thevoltage
value measured and displayed on the LCD is a reference
value.Pleasenotethattheindicatedvalue,whenanexternal
ACvoltageisappliedtotheinstrument,isnotacorrectvalue.
【Voltagemeasurementrange】
DCvoltage ACvoltage
Measuringrange ±30-±600V 30-600V(50/60Hz)
Resolution 1V
Accuracy ±2%rdg±3dgt
