L-Acoustics K2 User Manual

Loudspeaker congurations
Loudspeaker congurations
Line source
Deployed as a line source, the system operates over the nominal bandwidth of the K2 enclosure, with an adjustable
horizontal directivity.
Two congurations are possible:
• K2 line source
• K2/K1-SB line source: enhanced LF throw
The [K2 70], [K2 90] and [K2 110] presets allow for a reference frequency response in long throw applications. Each
preset is dedicated to a horizontal directivity setting.
By providing the K1-SB with the same frequency response as the K2 low section, the [K1SB_X K2] preset allows the K1-SB
enclosure to be used as an LF line source element, increasing the length of the sub-low line source.
The K2 enclosures are driven by the LA4X / LA8 amplied controllers.
The K1-SB enclosures are driven by the LA8 amplied controller.
Standalone K2 line source
[K2 70] / [K2 90] / [K2 110]
[PRESET]
Enclosure K2
Preset [K2 70] [K2 90] [K2 110]
Frequency range (-10 dB) 35 Hz - 20 kHz
10 K2/SB28 user manual (EN) version 7.0

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
