L-Acoustics K2 User Manual

Technical description
K1-SB applications
There are two distinct applications for K1-SB in a K2 system:
• As an LF extension in a line source for enhanced throw, using the [K1SB_X K2] preset with K2.
• As a subwoofer for increased impact, using the [K1SB_60] preset.
Both applications of K1-SB can be combined in the same conguration.
K1-SB as an LF extension in a line source K1-SB as a subwoofer
K2 LINE SOURCE /
K2/K1-SB LINE SOURCE
K2 LINE SOURCE /
K2/K1-SB LINE SOURCE
ENHANCED THROW INCREASED IMPACT
K2/SB28 user manual (EN) version 7.0 9

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
