L-Acoustics K2 User Manual

Recommendation for speaker cables
Recommendation for speaker cables
Follow the recommended maximum length for loudspeaker cables to ensure minimal SPL attenuation.
Cable quality and resistance
Only use high-quality fully insulated speaker cables made of stranded copper wire.
Use cables with a gauge offering low resistance per unit length and keep the cables as short as possible.
The table below provides the recommended maximum length for loudspeaker cables depending on the cable gauge and
on the impedance load connected to the amplier.
recommended maximum lengthcable gauge
8 Ω load 4 Ω load 2.7 Ω load
mm
2
SWG AWG m ft m ft m ft
2.5 15 13 30 100 15 50 10 33
4 13 11 50 160 25 80 17 53
6 11 9 74 240 37 120 25 80
For your installation projects, you can use the more detailed L-ACOUSTICS calculation tool to evaluate cable length and
gauge based on the type and number of enclosures connected. The calculation tool is available on our website:
http://www.l-acoustics.com/installation-outils-de-calcul-137.html
26 K2/SB28 user manual (EN) version 7.0

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
