L-Acoustics K2 User Manual

Loudspeaker connection
Connection to LA4X
Maximum number of enclosures per LA4X
enclosure max enclosures in parallel * max enclosures per controller
K2 1 1
Kara 2 4
*For passive loudspeakers, the value corresponds to the number of enclosures in parallel on the output. For active
loudspeakers, the value corresponds to the number of sections in parallel on the output.
Impedance load
K2
1 enclosure: LF 8 Ω / MF 8 Ω / HF 16 Ω
Kara
1 enclosure: LF 8 Ω / HF 8 Ω
2 enclosures in parallel: LF 4 Ω / HF 4 Ω
Connecting 3-way active enclosures
custom speakON-to-PA-COM on speakON output
L-Acoustics does not supply the speakON-to-PA-COM interface.
It must be built with two 4-point speakON connectors and a female 8-point PA-COM connector (no cable clamp).
OUT1/OUT2
OUT3/OUT4
speakON to PA-COM
Connecting 2-way active enclosures
SP on speakON output
SP
OUT1/OUT2 OUT3/OUT4
same as OUT1/OUT2
SP
K2/SB28 user manual (EN) version 7.0 21

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
