L-Acoustics K2 User Manual

Loudspeaker congurations
Delay values
Do not forget to add the pre-alignment and geometric delays depending on the conguration.
When using [K2 70], [K2 90], or [K2 110] with [K1SB_X K2], do not add any delay value between the K2 and
K1-SB elements of a same line source.
Pre-alignment delays
[K2] + [SB28_60] K2 = 0 ms SB28 = 6 ms
[K2] + [SB28_60_C] K2 = 0 ms SB28 = 0.5 ms
[K2] + [K1SB_60] +
[SB28_60]
K2 = 8 ms K1-SB = 2 ms SB28 = 0 ms
[K2] + [K1SB_60] +
[SB28_60_C]
K2 = 13.5 ms K1-SB = 7.5 ms SB28 = 0 ms
K2/SB28 user manual (EN) version 7.0 17

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
