L-Acoustics K2 User Manual

Loudspeaker connection
DO and DOFILL-LA8 on CA-COM output
CA-COM
DO
DOFILL-LA8
SP
2W CH(A) (OUT1/OUT2)
2W CH(B) (OUT3/OUT4)
Connecting a 2-way active enclosure with subwoofers
DO and DO3WFILL on CA-COM output
CA-COM
DO
DO3WFILL
2WAY (OUT3/4)
SUB1 (OUT1)
SUB2 (OUT2)
SP
SP
SP
Connecting subwoofers
SP and SP-Y1 on speakON output
OUT1/OUT2
OUT3/OUT4
same as OUT1/OUT2
SP SP-Y1
CC4FP
CH(1) (OUT1)
CH(2) (OUT2)
K2/SB28 user manual (EN) version 7.0 23

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
