L-Acoustics K2 User Manual

System components
Software applications
Soundvision 3D acoustical and mechanical modeling software
LA Network Manager Software for remote control and monitoring of amplied controllers
Refer to the Soundvision help.
Refer to the LA Network Manager help.
Loudspeaker cables
0.7 m / 5 m / 10 m / 25 m
CH(1)
CH(2)
1 m
SP.7 / SP5 / SP10 / SP25 SP-Y1
0.7 m / 10 m / 25 m
SPK1
SPK2
SPK3
SPK4
5 m
DO.7 / DO10 / DO25 DOSUB-LA8
2W CH(A)
2W CH(B)
3.5 m
2WAY
SUB1
SUB2
3.5 m
DOFILL-LA8 DO3WFILL
K2/SB28 user manual (EN) version 7.0 7

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
