L-Acoustics LA4X User Manual

Operation
Main menu pages
Page Functionalities Reference
LOAD PRESET USER load a user preset (from memories 1 to 10)
LOAD PRESET
FACTORY
load a factory preset (from memories 11 to 199)
LOAD PRESET
(p.35)
STORE PRESET save the current preset (including current settings) as a user preset (in a
memory from 1 to 10)
STORE PRESET
(p.37)
DELETE PRESET delete a user preset (in memory from 1 to 10) DELETE PRESET
(p.38)
PRESET PARAMETERS set parameters for gain, delay, polarity and input selection PRESET PARAMETERS
(p.38)
CLEAR GROUP
PARAMS
remove the group parameters dened in LA Network Manager (name,
gain, delay, and Contour EQ)
CLEAR GROUP
PARAMS (p.40)
INPUT SETTINGS set the input mode, fallback mode and AES/EBU gain INPUT SETTINGS
(p.41)
MONITORING &
INFO
display real-time measured values: RMS output voltage and output
temperature (in percentage of the maximum values)
display rmware and preset library versions and amplied controller's
MAC address
launch ENCLOSURE CHECK
MONITORING &
INFO (p.45)
OPTIONS
set the amplied controller's IP address, delay unit, screen contrast
reset all parameters to factory settings
OPTIONS (p.47)
All parameters can also be selected from LA Network Manager. Refer to the LA Network Manager video
tutorial.
LOAD PRESET
A preset can be loaded from two pages:
Page Memory range Contents
LOAD PRESET USER 1 to 10 (read and write) User presets stored by user — refer to STORE PRESET (p.37)
LOAD PRESET FACTORY 11 to 199 (read only) Factory preset library created by L-Acoustics and automatically
installed during rmware update (refer to the LA Network
Manager video tutorial)
35 LA4X user manual (EN) version 9.1
