Operation
MONITORING & INFO
The MONITORING & INFO menu provides real-time measurements and information on the amplied controller:
— For each output channel:
— real-time RMS output voltage (in percentage of the maximum value supported by the connected transducer
section)
— output temperature (in percentage of the operating range)
— Ethernet ports current status
— version numbers of the amplied controller onboard rmware and preset library
— amplied controller's MAC address
— amplied controller's hardware version
— the ENCLOSURE CHECK function
MONITORING & INFO
‾SPK HANDLING (%) ‼
12% 10% 13% 11%
‽OUT CH TEMP (%) ‼
52% 53% 50% 48%
‽FIRMWARE ‼
V1.7.2
‽PRESET LIBRARY ‼
V5.6
‿ENCLOSURE CHECK ‼
WARMUP COUNTDOWN 09:42
‽MAC ADDRESS ‼
00:1B:92:01:90:3A
‽HARDWARE INFO ‼
ID4
‽MONITORING & INFO ‼※
OPTIONS
OK
‽ETHERNET LINKS ‼
1: 1G FULL 2:100 FULL
SPK HANDLING (%)
SPK HANDLING (%) (speaker handling) displays the RMS voltage measured at each individual amplier circuit output as
a percentage of the maximum voltage supported by the connected speaker section.
In illustration MONITORING & INFO (p.45), the RMS voltage of channels OUT 1 to OUT 4 is respectively 12, 10,
13, and 11 % of the maximum values.
OUT CH TEMP (%)
OUT CH TEMP (%) (output channel temperature) displays the temperature measured at each individual amplier circuit
output as a percentage of the maximum operating temperature supported by the amplied controller: 60° C / 140° F =
100%.
In illustration MONITORING & INFO (p.45), the temperature of channels OUT 1 to OUT 4 is respectively 52, 53, 50,
and 48 % of the maximum values.
Refer to Error messages (p.53) for information on the temperature-related messages.
