Marine Systems
Aviation Recorders
Rev. 02 Page 1--7
July 29/03
Automatic Identification System
TDMA Receiver
RX Frequency: 156.025 MHz -- 162.025 MHz, 2 channels
RX1: Default CH87B (161.975 MHz), manual/automatic setting
RX2: Default CH88B (162.025 MHz), manual/automatic setting
Channel Spacing: 25 kHz and 12.5 kHz
DSC Receiver
RX Frequency: CH70 (156.525 MHz)
Internal GPS Receiver
12 Channel, UTC Synchronization Jitter (time between slot start and transmitter on):
± 100 μs
Navigational data
COG/SOG, ROT, POS, Heading from external sources
Display
Integral MKD with 160 x 64 Dots backlit LCD
INTERFACE
Input ABM,ACA,ACK,AIR,BBM,DTM,GBS,GGA,GLL,GNS,HDT,
OSD,
SSD, RMC, ROT, VBW, VSD, VTG
Output ABK, VDO, VDM, ACA, ACS, ALR, LRF, LR1, LR2, LR3, TXT
Power Supply
12--24 VDC nominal, complies with IEC 60945
Power Supply requirements, 2.5--5 A, 115/230 VAC with Converter
Environment
IEC 60945 for Protected Environment
Frequency
VHF Marine Band
