Marine Systems
Aviation Recorders
Rev. 02 Page viii
July 29/03
Automatic Identification System
TABLE OF CONTENTS
(Continued)
SUBJECT/DESCRIPTION PAGE
SECTION 2 -- ProTec AIS Operation
2.1. Operation 2--3................................................................
2.1.1. Minimum Keyboard Display 2--3................................................
2.1.1.1Power/Dim Control 2--4........................................................
2.1.1.2Liquid Crystal Display 2--4.....................................................
2.1.1.3Key Pad 2--4.................................................................
2.1.1.4Pilot Port 2--4................................................................
2.1.2. Keypad Description 2--4.......................................................
2.1.3. Data Display Screens 2--6.....................................................
2.1.4. Data Entry Screens 2--8.......................................................
2.1.4.1Vessel Data Setup 2--9........................................................
2.1.4.2Channel Management 2--11....................................................
2.1.4.3Antenna Position 2--12........................................................
2.1.4.4Text Messaging 2--13.........................................................
2.1.4.5Password Entry 2--15.........................................................
2.1.4.6Change Password 2--16.......................................................
2.1.4.7System Alert Screen 2--17.....................................................
2.1.4.8Alarm Status 2--17............................................................
2.1.4.9Down--Time Log 2--18.........................................................
SECTION 3 -- ProTec AIS Installation
3.1. Installation 3--3...............................................................
3.1.1. Transponder 3--4.............................................................
3.1.2. Connecting the IEC Data Interface Cable 3--9....................................
3.1.2.1Data Channels 3--9...........................................................
3.1.2.2Data Cable 3--10.............................................................
3.1.2.3Terminal Block 3--13..........................................................
3.1.3. Installing the VHF Antenna 3--15...............................................
3.1.4. Installing the GPS Antenna 3--16...............................................
3.1.5. PowerUp and Configuration 3--19...............................................
