L3 comminications ProTec - Figure 3-3. AIS Transponder O&D Drawing

Marine Systems
Aviation Recorders
Rev. 02 Page 3--6
July 29/03
Automatic Identification System
7.23 in. ¦ .12
0.625
in.
6.40 ¦ .06
184 mm ¦ 3
163 mm
¦ 1.5
15.875 mm
3.28 in.
¦ .06
3.14 in.
¦ .06
2.937 in.
¦ .06
80 mm
¦ 1.5
75 mm
¦ 1.5
83 mm
¦ 1.5
Figure 3--3. AIS Transponder O&D Drawing
