L3 comminications ProTec - Figure 3-2. AIS Transponder O&D Drawing with Trunion Bracket

Marine Systems
Aviation Recorders
Rev. 02 Page 3--5
July 29/03
Automatic Identification System
7.23 in. ¦ .12
0.625
in.
1.25 in.
1.25 in.
1.25 in.
0.88 in.
7.81 in. ¦ .12
6.87 in. ¦ .12
6.40 in. ¦ .06
3.28 in.
¦ .06
3.73 in.
¦ .12
3.14 in.
¦ .06
2.937 in.
¦ .06
80 mm
¦ 1.5
75 mm
¦ 1.5
83 mm
¦ 1.5
95 mm
¦ 3
174 mm
¦ 3
163 mm
¦ 1.5
22 mm
31.75 mm
31.75 mm
31.75 mm
198 mm
¦ 3
184 mm ¦ 3
16 mm
Figure 3--2. AIS Transponder O&D Drawing with Trunion Bracket
