L3 comminications ProTec - Figure 3-4. AIS Transponder Power Cable

Marine Systems
Aviation Recorders
Rev. 02 Page 3--7
July 29/03
Automatic Identification System
Black
RedGreen
White
ID MARK
1.8 m ¦ 0.05 m
25 mm
¦ 6mm
Cable End
Signal Table for “Cable Assembly, Power/BIIT, External”
Line Color Name Description Function Power
1 Black B(--) Battery, negative Power return -- --
2 Red B(+) Battery, positive Power input +12VDC/5A to +24VDC/2.5A
(nominal voltages)
3 Green BIIT 1 BIIT relay, terminal 1 BIIT Status Contact closure
2
2
0
V
D
C
/
2
A
D
C
/
6
0
W
4 White BIIT 2 BIIT relay, terminal 2
2
2
0
V
D
C
/
2
A
D
C
/
6
0
W
maximum
Figure 3--4. AIS Transponder Power Cable
