Automatic Identification System
1.4.2. Pilot Systems Outpu t Data and Formats
The output data and formats are shown in Table 1--3, and the details of the sen-
tences can be found in IEC 61162--1.
Table 1--3. Pilot System High--Speed Outpu t Data Formats
Data IEC 61162--1 Sentences
Prepared by AIS Transponder
Notification that a session initiated by messages
ABM, BBM, ACA, AIR is terminated
ABK -- Acknowledgement Message
AIS Own--ship broadcast data (all transmissions
available)
VDO -- VHF Data--link Own--vessel Message
Query response messages ACA -- AIS Channel Assignment
SSD -- Station Static Data
VSD -- Voyage Static Data
BIIT Results
AIS equipment status ALR -- Alarm Message
TXT -- Status / Indication Message
Received from Long Range Equipment
LR Interrogation LRI -- Long Range Interrogation
LR Function identification LRF -- Long Range Function
Received on VHF Data Link by AIS Transponder
All VDL AIS messages received
-- Broadcast or
-- Addressed to own station
VDM -- VHF Data Link Message
1.4.3. Pilot Input / Output Port
The Pilot input/output port is a part of the AIS Class A stations. If the installation of
the AIS equipment is such that a pilot cannot connect his Personal Pilot Unit (PPU)
with a reasonable length of cable, an extension cable must be installed with a con-
nector located on the bridge such that the PPU can be connected on the normal
working position of the port.
