Marine Systems
Aviation Recorders
Rev. 02 Page 3--14
July 29/03
Automatic Identification System
NOTE: Each shielded twisted pair of wires is shielded as well by
metallic shielding and a drain wire connected to this shield-
ing is to be connected in accordance with Table 3--2.
Table 3--2. IEC Cable and Junction Box Pinouts
Cable STP Wire Color IEC Pin TB Pin
1 White / Blue 1 1
Blue / White 11 2
Drain 22 3
2 White / Orange 2 4
Cable 1
Orange / White 12 5
Drain 25 6
3 White / Green 3 7
Green / White 13 8
Drain 23 9
Shield Drain NC 10
4 White / Brown 4 11
Brown / White 14 12
Drain 24 13
5 White / Gray 5 14
Cable 2
Gray / White 15 15
Drain 26 16
6 Red / Blue 6 17
Blue / Red 16 18
Drain 27 19
Shield Drain NC 20
7 Red / Orange 8 21
Orange / Red 19 22
Drain 29 23
8 Red / Green 9 24
Cable 3
Green / Red 20 25
Drain 30 26
9 Red / Brown 10 27
Brown / Red 21 28
Drain 31 29
Shield Drain 18 30
To Next Page
