La Spaziale COMPACT - Dose Setting

INSTRUCTIONMANUALFORTHEINSTALLER


Thisfunctionisusedexclusivelybythemanufacturerofthecontrolboard.


1stDOSE:90pulses 3rdDOSE:145pulses
2ndDOSE:100pulses 4thDOSE:160pulses
Tochangethesedefaultsettings,proceedasfollows:
MoveDIP3toONandpressthebutton
,presetthedisplayforpulsecounting(thenumber“Ø”is
shown).
Attachalterholderforonegroundcoffeedose(11b)tothe1stgroupontheright;placeacupbelow
thelterholderandpushthebutton
onthecorrespondingtouchpad.
Whenthedesiredamountofcoffeehasbeendeliveredintothecup,pressthebutton againandtake
noteofthenumberofpulsesonthedisplay(33).


Nowholddownthebuttons
or forabout,untilthedisplay(33)shows“”,(settingof
the1stdeliverygroupfromtheright)andalloftheLEDsontheright-handtouchpadstarttoash.
Pressthebutton“1shortcoffee”(25)onthetouchpadandusebuttons
or tochangethesetting
onthedisplay(33),tothesamenumberofpulsesnotedpreviouslyforthe“1shortcoffee”dose.
Pressthebutton“1shortcoffee”(25)onthetouchpadagaintoconrmandstorethenewsetting.
Repeatthisoperationfortheother3buttonsonthesametouchpad(26-27-28).
Afterprogrammingthersttouchpad,ifyoualsowanttocopythesamedosestotheotherpads,holddown
thebutton
SET
foraboutuntilalloftheLEDsonalloftheappliancetouchpadslightup.
Afterthisoperation,moveDIP3totheOFFpositionandclosetheelectronicbox.
 













